Antennas - 900 MHz Band Antennas

Indoor Mount Vertical Whip Antenna

This indoor mount vertical whip antenna is designed for short range work. It has a gain of 2.1 dBi and a radiation pattern shaped like a horizontal donut.

A swivel joint at the bottom allows it to be mounted on a vertical or horizontal surface. It mounts by screwing on to a Reverse Polarity SMA female connector.

Specifications

 Antenna,900 MHz Band Antennas,2400 MHz,2.4 GHz,Band Antennas,Indoor Mount Vertical Whip,Omni Directional,Yagi,Dual Band Mobile,Wilkerson Instrument
Frequency: 902-928 MHz Base Material: Polyacetal (Black)
Impedance: 50 ohms Nominal Connector: RPSMA Male
Length: 6.73"

View Whip Antenna Data Sheet

Omni Directional Vertical Antenna

These vertical antennas also have a radiation pattern shaped like a horizontal donut, but have a higher gain and are designed for outdoor use. They are useful for a master antenna in a polling system where the control transmitter and receiver must send and receive to several slave units dispersed over a broad azimuth angle.

Specifications
Antenna,900 MHz Band Antennas,2400 MHz,2.4 GHz,Band Antennas,Indoor Mount Vertical Whip,Omni Directional,Yagi,Dual Band Mobile,Wilkerson Instrument
Gain (27"): 6dBi Radiator: Copper Alloy
Gain (52"): 8.5dBi Sheath: UV Inhibited White ABS
Impedance: 50 ohms Termination: Type N Female

View 27" Omni Directional Vertical Antenna Data Sheet

View 52" Omni Directional Vertical Antenna Data Sheet

Yagi Antenna

Yagi antennas achieve more gain than verticals by concentrating radiation in a single direction. Their reduced gain from the back end helps keep other signals from interfering with normal operation. The front to back ratio is an important characteristic of a yagi antenna.

A yagi antenna can be operated with the elements mounted vertically or horizontally. The most common use for industrial wireless is vertical. The transmitting and receiving antenna must both have the same element polarization for satisfactory operation. A large loss in signal is experienced when the elements are crossed polarized. This characteristic can be used to reduce or eliminate interference between systems.

When a vertical omnidirectional antenna is used on the control end of a polling system, a vertically polarized yagi can be used on each slave unit for maximum gain and reduction in interference due to the front to back ratio gain reduction characteristic of the yagi.

Parabolic Antenna

The Parabolic Antenna can only receive signals from the front. It is the antenna of choice for long range work or in areas of potentially high interference.



View Parabolic Antenna Data Sheet

 Antenna,900 MHz Band Antennas,2400 MHz,2.4 GHz,Band Antennas,Indoor Mount Vertical Whip,Omni Directional,Yagi,Dual Band Mobile,Wilkerson Instrument

Antennas - 2400 MHz (2.4 GHz) Band Antennas

Antenna,900 MHz Band Antennas,2400 MHz,2.4 GHz,Band Antennas,Indoor Mount Vertical Whip,Omni Directional,Yagi,Dual Band Mobile,Wilkerson Instrument

Vertical Indoor Mount Whip Antenna

This indoor mount vertical antenna is designed for short range work. It has a gain of 2.1 dBi and a radiation pattern shaped like a horizontal donut.

A swivel joint at the bottom allows it to be mounted on a vertical or horizontal surface. It mounts by screwing on to a Reverse Polarity SMA female connector.

Specifications

 Antenna,900 MHz Band Antennas,2400 MHz,2.4 GHz,Band Antennas,Indoor Mount Vertical Whip,Omni Directional,Yagi,Dual Band Mobile,Wilkerson Instrument
Frequency: 2.4/2.5 GHz Base Material: Polyurethane (Black)
Impedance: 50 ohms Nominal Connector: RPSMA Male
Length: 5.38"

View Vertical Indoor Mount Whip Antenna Data Sheet

Dual Band Mobile Antenna

This outdoor mount vertical antenna is designed for short range work. It has a gain of 2.1 dBi and a radiation pattern shaped like a horizontal donut. It performs equally
well on the 900 MHz or 2.4 GHz band.

Specifications

 Antenna,900 MHz Band Antennas,2400 MHz,2.4 GHz,Band Antennas,Indoor Mount Vertical Whip,Omni Directional,Yagi,Dual Band Mobile,Wilkerson Instrument
Frequency: 880/1200MHz and 2.3/2.6GHz Base Material: ABS Black
Impedance: 50 ohms Nominal Connector: RPSMA Male
Length: 2.75 Radiator: Polyester coated brass

View Dual Band Mobile Antenna Data Sheet

Omni Directional Vertical Antenna

This vertical antenna has a radiation pattern shaped like a horizontal donut, has a high gain and is designed for outdoor use. It is useful for a master antenna in a polling system where the control transmitter and receiver must send and receive to several slave units dispersed over a broad azimuth angle.

Specifications

 Antenna,900 MHz Band Antennas,2400 MHz,2.4 GHz,Band Antennas,Indoor Mount Vertical Whip,Omni Directional,Yagi,Dual Band Mobile,Wilkerson Instrument
Gain: 8dBi Radiator(20"): Copper Alloy
Impedance: 50 ohms Sheath: UV Inhibited White ABS
    Termination: Type N Female

View Omni Directional Vertcal Antenna Data Sheet

Yagi Antenna

Antenna,900 MHz Band Antennas,2400 MHz,2.4 GHz,Band Antennas,Indoor Mount Vertical Whip,Omni Directional,Yagi,Dual Band Mobile,Wilkerson InstrumentYagi antennas achieve more gain than verticals by concentrating radiation in a single direction. Their reduced gain from the back end helps keep other signals from interfering with normal operation. The front to back ratio is an important characteristic of a yagi antenna.

A yagi antenna can be operated with the elements mounted vertically or horizontally. The most common use for industrial wireless is vertical. The transmitting and receiving antenna must both have the same element polarization for satisfactory operation. A large loss in signal is experienced when the elements are crossed polarized. This characteristic can be used to reduce or eliminate interference between systems.

When a vertical omnidirectional antenna is used on the control end of a polling system, a vertically polarized yagi can be used on each slave unit for maximum gain and reduction in interference due to the front to back ratio gain reduction characteristic of the yagi.

View 18" Yagi Antenna Data Sheet

Antenna Cable Assemblies
P/N
Length/Cable Type
Connector 1
Connector 2
Loss
900MHz
2.4GHz
CPT2
2 Ft WBC195
RPSMA Male
N Male
0.5dB
0.8dB
CPT6
6 Ft WBC195
RPSMA Male
N Male
1.0dB
1.6dB
CPT10
10 Ft WBC195
RPSMA Male
N Male
1.5dB
2.3dB
C400NM-NF-10
10Ft WBC400
N Male
N Female
0.7dB
1.1dB
C400NM-NF-20
20Ft WBC400
N Male
N Female
1.1dB
1.8dB
C400NM-NF-30
30Ft WBC400
N Male
N Female
1.5dB
2.5dB
C400NM-NF-40
40Ft WBC400
N Male
N Female
1.9dB
3.1dB
C400NM-NF-50
50Ft WBC400
N Male
N Female
2.3dB
3.8dB
C400NM-NF-75
75Ft WBC400
N Male
N Female
3.3dB
5.5dB
C400NM-NF-100
100Ft WBC400
N Male
N Female
4.2dB
7.2dB
C400NM-NM-10
10Ft WBC400
N Male
N Male
0.7dB
1.1dB
C400NM-NM-20
20Ft WBC400
N Male
N Male
1.1dB
1.8dB
C400NM-NM-30
30Ft WBC400
N Male
N Male
1.5dB
2.5dB
C400NM-NM-40
40Ft WBC400
N Male
N Male
1.9dB
3.1dB
C400NM-NM-50
50Ft WBC400
N Male
N Male
2.3dB
3.8dB
C400NM-NM-75
75Ft WBC400
N Male
N Male
3.3dB
5.5dB
C400NM-NM-100
100Ft WBC400
N Male
N Male
4.2dB
7.2dB

Bulk Coaxial Cable

P/N
Cable Type
Loss/100Ft
Diameter
Weight
900MHz
2.4GHz
4000
WBC195
11.1dB
19dB
0.195"
0.021 lb/ft
4005
WBC400
3.9dB
6.8dB
0.405"
0.068 lb/ft
4082
Tool
Crimping tool for WBC400 cable and Type N connector.

Connectors/Couplers/Surge Arrestors

P/N
Type
Description
3978
RPSMA Male
WBC195 cable bulkhead connector. Fits 4007 & 4008 dipole antennas
4003
Type N Male
Fits WBC400 cable. Connects to Type N bulkhead or antenna connector
4006
Type N Female
Fits WBC400 cable. Connects to Type N Male connector. Use to join cables
4010
Type N Male
Fits WBC195 cable. Mates with Type N bulkhead connector or join cables
4026
Type N
Female/Female bulkhead connector to pass coaxial cable through panel
4073
2 Port Coupler
900MHz coupler, 0.4dB insertion loss. Share antennas, DR9021/DR9051
4051
4 Port Coupler
900MHz coupler, 0.4dB insertion loss. Share antennas, DR9021/DR9051
4061
4 Port Coupler
2.4GHz coupler, 0.4dB insertion loss. Share antennas, DR9021/DR9051
4062
Termination
50 ohm termination, type N Male. Use to terminate open ports on couplers
4011
Arrestor
Type N Male to Female Lightning surge arrestor. 0.4dB insertion loss
4035
Arrestor
Type N Male to Male Lightning surge arrestor. 0.1dB insertion loss
